Power Analyzer/Renewable Energy
Brand : Carlo Gavazzi
|
Model : EM21-72V Series |
Type : Energy Meter Analyzer Properties
Conectivity
RS485 Depend on ordered
screen size
LCD, 7 mm character height Dimensions: 72 × 72 mm
installation
Panel mount
body size
72 × 72 mm
Accuracy
±0.5% RDG , Class A
operating temperature range
-20°C to +55°C
Weight
Approx. 400 g
power supply
18V - 260VAC
output
Static output (Opto-MOSFET), 1 pulse output; RS485 optional
Measuring range
Electrical system can measure both 1-phase and 3-phase, used to measure with electrical cabinets that have a narrow space
measure current
Split-core current measurement CT model CVT-1X-Series : 60A, 100A, 200A, 400A
pressure gauge
400 VAC , 660 VAC
IP
IP50
details
Cabinet-mounted electric energy meter 72x72X65mm and built-in DIN rail type
Data Sheet
