Power Analyzer/Renewable Energy
Brand : Carlo Gavazzi
|
Model : EM340-Series |
Type : Energy Meter Analyzer Properties
Conectivity
RS485 (Optional)
screen size
Size : 3-line × 8-digit LCD with Backlight
installation
DIN-Rail Mount
body size
54 × 90 × 63 mm (W × H × D)
Accuracy
±0.5% RDG
operating temperature range
-25°C to +65°C
Weight
240 g
power supply
Self-powered from the measured voltage, 208–400 VAC (L-L)
output
Optional (Selectable when ordering)
Measuring range
True RMS measurement with W, VA, PF, var, V, A and kWh parameters VLL, VLN, Hz, kW, kvar, kVA, kWh, kvarh and Demand
measure current
5(65) A, Direct Connection
pressure gauge
208–400 VAC (L-L)
IP
Front: IP51 / Terminals: IP20
details
Three-phase Energy Meter
Data Sheet
